I have seen many Linux Performance engineers looking at the “IOWait” portion of CPU usage as something to indicate whenever the system is I/O-bound. In this blog post, I will explain why this approach is unreliable and what better indicators you can use.
Let’s start by running a little experiment – generating heavy I/O usage on the system:
Shell
1 | sysbench--threads=8 --time=0 --max-requests=0fileio --file-num=1 --file-total-size=10G --file-io-mode=sync --file-extra-flags=direct --file-test-mode=rndrd run |
CPU Usage in Percona Monitoring and Management (PMM):
Shell
1 2 3 4 5 6 7 8 9 | root@iotest:~# vmstat 10 procs -----------memory---------- ---swap-- -----io---- -system-- ------cpu----- rb swpd free buffcache si sobibo in cs us sy id wa st 360 713715226452 76297200 405001714 2519 469316 55 353 280 713810026476 76296400 34497117 20059 378653 137 735 080 713916026500 76301600 34744837 20599 379354 175 723 270 713973626524 76296800 33473014 19190 362563 154 716 440 713948426536 76290000 253995 6 15230 279342 116 774 070 713948426536 76290000 350854 6 20777 383452 133 775 |
So far, so good, and — we see I/O intensive workload clearly corresponds to high IOWait (“wa” column in vmstat).
Let’s continue running our I/O-bound workload and add a heavy CPU-bound load:
Shell
1 | sysbench --threads=8 --time=0 cpu run |
Shell
1 2 3 4 5 6 7 8 9 10 11 12 | root@iotest:~# vmstat 10 procs -----------memory---------- ---swap-- -----io---- -system-- ------cpu----- rb swpd free buffcache si sobibo in cs us sy id wa st 1240 712164026832 76347600 480341460 2895 544367 47 373 1330 712041626856 76346400 25646414 12404 25937 69 1500 16 880 712102026880 76349600 32578916 15788 33383 85 15000 1060 712146426904 76346000 32295433 16025 33461 83 15001 970 712359226928 76352400 33679414 16772 34907 85 15001 1330 712413226940 76355600 38638410 17704 38679 84 16000 970 712825226964 76360400 35619813 16303 35275 84 15000 970 712805226988 76358400 32472314 13905 30898 80 15005 1060 712202027012 76358400 38042916 16770 37079 81 18001 |
What happened? IOWait is completely gone and now this system does not look I/O-bound at all!
In reality, though, of course, nothing changed for our first workload — it continues to be I/O-bound; it just became invisible when we look at “IOWait”!
To understand what is happening, we really need to understand what “IOWait” is and how it is computed.
There is a good article that goes into more detail on the subject, but basically, “IOWait” is kind of idle CPU time. If the CPU core gets idle because there is no work to do, the time is accounted as “idle.” If, however, it got idle because a process is waiting on disk, I/O time is counted towards “IOWait.”
However, if a process is waiting on disk I/O but other processes on the system can use the CPU, the time will be counted towards their CPU usage as user/system time instead.
Because of this accounting, other interesting behaviors are possible. Now instead of running eight I/O-bound threads, let’s just run one I/O-bound process on four core VM:
Shell
1 | sysbench--threads=1 --time=0 --max-requests=0fileio --file-num=1 --file-total-size=10G --file-io-mode=sync --file-extra-flags=direct --file-test-mode=rndrd run |
Shell
1 2 3 4 5 6 7 8 9 10 11 12 | procs -----------memory---------- ---swap-- -----io---- -system-- ------cpu----- rb swpd free buffcache si sobibo in cs us sy id wa st 310 713030827704 76359200 6200012 4503 857735 69 203 210 712714427728 76359200 6709814 4810 925325 70 202 210 712844827752 76359200 7276015 5179 994625 72 201 400 713306827776 76358800 6956629 4953 956225 72 211 210 713132827800 76357600 6750115 4793 927625 72 201 200 712813627824 76359200 5946115 4316 827225 71 203 310 712971227848 76359200 6413913 4628 885425 70 203 200 712898427872 76359200 7102718 5068 971826 71 201 100 712823227884 76359200 6977912 4967 954925 71 201 500 712850427908 76359200 6641918 4767 913925 71 201 |
Even though this process is completely I/O-bound, we can see IOWait (wa) is not particularly high, less than 25%. On larger systems with 32, 64, or more cores, such completely IO-bottlenecked processes will be all but invisible, generating single-digit IOWait percentages.
As such, high IOWait shows many processes in the system waiting on disk I/O, but even with low IOWait, the disk I/O may be bottlenecked for some processes on the system.
If IOWait is unreliable, what can you use instead to give you better visibility?
First, look at application-specific observability. The application, if it is well instrumented, tends to know best whenever it is bound by the disk and what particular tasks are I/O-bound.
If you only have access to Linux metrics, look at the “b” column in vmstat, which corresponds to processes blocked on disk I/O. This will show such processes, even of concurrent CPU-intensive loads, will mask IOWait:
Finally, you can look at per-process statistics to see which processes are waiting for disk I/O. For Percona Monitoring and Management, you can install a plugin as described in the blog post Understanding Processes Running on Linux Host with Percona Monitoring and Management.
With this extension, we can clearly see which processes are runnable (running or blocked on CPU availability) and which are waiting on disk I/O!
